Specifications

PRICING

Price	Standard
Price - Warranty (Months)	12
Price - Warranty (Condition)	Limited

ENGINE

Engine	Standard
Engine - Engine Type	V Twin
Engine - Cylinders	2
Engine - Engine Stroke	4-Stroke
Engine - Horsepower (bhp)	79
Engine - Horsepower (kW)	58.9
Engine - Horsepower RPM	7000
Engine - Torque (Ft Lbs)	60
Engine - Torque (Nm)	81.3
Engine - Torque RPM	6200
Engine - Cooling	Liquid
Engine - Valves	8
Engine - Valves Per Cylinder	4
Engine - Valve Configuration	SOHC
Engine - Displacement (cc)	963
Engine - Displacement (ci)	58.7
Engine - Starter	Electric
Engine - Fuel Requirements	Regular
Engine - Fuel Type	Gas
Carburetion	Standard
Carburetion - Carburetion Brand	Bosch
Carburetion - Fuel Injector	Yes
Carburetion - Carburetor	No
Carburetion - Carburetion Type	Fuel Injected

TRANSMISSION

Transmission	Standard
Transmission - Transmission Type	Continuously Variable (CVT)
Transmission - Primary Drive (Rear Wheel)	Shaft
Transmission - Primary Drive (Engine / Transmission)	Chain
Transmission - Reverse	Yes
Transmission - Hi / Low Range	Yes
Transmission - Primary Drive (Front Wheel)	Shaft

TECHNICAL SPECIFICATIONS

Dimensions	Standard
Dimensions - Length (in)	118
Dimensions - Length (mm)	2997.2
Dimensions - Width (in)	61
Dimensions - Width (mm)	1549.4
Dimensions - Height (in)	71
Dimensions - Height (mm)	1803.4
Dimensions - Wheelbase (in)	90
Dimensions - Wheelbase (mm)	2286
Dimensions - Ground Clearance (in)	12.2
Dimensions - Ground Clearance (mm)	309.9
Dimensions - Length (ft)	9.83
Dimensions - Length (ft/ft)	9
Dimensions - Length (ft/in)	10
Weight	Standard
Weight - Dry Weight (lbs)	1400
Weight - Dry Weight (kg)	635
Weight - Towing Capacity (lbs)	550
Weight - Towing Capacity (kgs)	249.5
Capacities	Standard
Performance	Standard
Performance - Engine Displacement to Weight (cc)	0.78

EXTERIOR

Construction	Standard
Construction - Frame	Steel
Construction - Body Material	Plastic
Exterior Guards	Standard
Exterior Guards - Chain Guard	No
Exterior Guards - Engine Case Guard	No
Exterior Guards - Brush Guard	Yes
Exterior Guards - Exhaust Guard	No
Exterior Guards - Front Mud Guards	No
Exterior Guards - Rear Mud Guards	No
Exterior Covers	Standard
Nerf Bars	Standard
Front Bumper	Standard
Rear Bumper	Standard
Front Fender Flairs	Standard
Rear Fender Flairs	Standard
Skid Plate	Standard
Skid Plate - A-Arm Skid Plate (Front)	Yes
Skid Plate - A-Arm Skid Plate (Rear)	Yes
Skid Plate - Bash Plate (Front)	Yes
Skid Plate - Full Length Skid Plate	Yes
Cab Canopy	Standard
Cab Canopy - Cab Canopy Material	Hard
Cab Canopy - Camouflage	No
Cab Cage	Standard
Cab Rollbar	Standard
Cab Doors	Standard
Cab Doors - Cab Door Material	Hard

SUSPENSION

Front Suspension	Standard
Front Suspension - Front Suspension Type	Independent Double A-Arm
Front Suspension - Front Travel (in)	11
Front Suspension - Front Travel (mm)	279.4
Front Suspension - Front Adjustable Fork Pre-Load	Yes
Rear Suspension	Standard
Rear Suspension - Rear Suspension Type	Independent A-Arm
Rear Suspension - Rear Travel (in)	11.8
Rear Suspension - Rear Travel (mm)	299.7
Rear Suspension - Rear Adjustable Shock / Spring Pre-Load	Yes
Rear Suspension - Number Rear Shock Absorbers	2
Rear Suspension - Rear Suspension Material	Steel
Rear Suspension - Air Adjustable	No

WHEELS & TIRES

Wheels	Standard
Wheels - Wheels Composition	Aluminum
Wheels - Tube / Tubeless	Tubeless
Wheels - Front Tire Diameter (in)	27
Wheels - Rear Tire Diameter (in)	27
Tires	Standard
Tires - Front Tire Width	9
Tires - Front Wheel Diameter	14
Tires - Rear Tire Width	11
Tires - Rear Wheel Diameter	14
Tires - Front Tire (Full Spec)	27 x 9 - 14
Tires - Rear Tire (Full Spec)	27 x 11 - 14
Tires - Tread Type	All Terrain

BRAKES

Brakes	Standard
Brakes - Front Brake Type	Hydraulic Disc
Brakes - Rear Brake Type	Hydraulic Disc
Engine Braking	Standard

SEATS

Seat	Standard
Seat - Seat Type	Bucket
Seat - Seat Material	Vinyl
Seat - Folding	No
Seat - Headrest	Yes
Seat Specifications	Standard
Seat Specifications - Number Of Seats	2
Seat Specifications - Number Of Rows	1
Grab Rail or Strap	Standard

INSTRUMENTATION

Digital Instrumentation	Standard
Clock	Standard
Trip Odometer	Standard
Speedometer	Standard
Temperature Warning	Standard
Temperature Warning - Temperature Warning Type	Gauge
Fuel Level Warning	Standard
Fuel Level Warning - Fuel Level Warning Type	Gauge

STORAGE

Cupholder	Standard
Cargo Bed	Standard
Cargo Bed - Bed Capacity (lbs.)	220
Cargo Bed - Bed Capacity (kgs.)	99.8
Cargo Bed - Cargo Bed Tilt	No
Cargo Bed - Integral Tie-Down Hooks	Yes
Glove Box / Dash Storage	Standard
Front Storage Well	Standard
Cargo Bed Cover	Standard
Cargo Bed Cover - Camouflage Trim	No

LIGHTS

Headlight(s)	Standard
Headlight(s) - Type	LED

CONVENIENCE

Power Outlet	Standard
Seat Belts	Standard

PAINT & FINISH

Paint	Optional
Paint - Primary Color	Black
Paint - Metallic	No

DRIVE LINE

Driveline	Standard
Driveline - Driveline Type	Selectable 4X2 / 4X4
Driveline - Number Of Driveline Modes	2
Driveline - Rear Unlocking Differential	No
Driveline - Rear Solid Axle	No
Differential Lock	Standard
Differential Lock - Differential Lock Location	Front

STEERING

Steering	Standard
Steering - Steering Type	Power
Steering - Steering Control	Steering Wheel
Tilt Steering	Standard

TOWING & HAULING

Rear Hitch	Standard
Rear Hitch - Size (in)	2
Rear Hitch - Size (cm)	5.1
Rear Hitch - Rear Hitch Type	Receiver
Winch	Standard
Winch - Weight (lbs)	3000
Winch - Weight (kgs)	1360.8
Roller Fairlead	Standard

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
