Specifications

PRICING

Price	Standard
Price - Warranty (Months)	12
Price - Warranty (Condition)	Limited

ENGINE

Engine	Standard
Engine - Engine Type	V Twin
Engine - Cylinders	2
Engine - Engine Stroke	4-Stroke
Engine - Horsepower (bhp)	71
Engine - Horsepower (kW)	53
Engine - Horsepower RPM	7000
Engine - Torque (Ft Lbs)	55
Engine - Torque (Nm)	74.6
Engine - Torque RPM	6500
Engine - Cooling	Liquid
Engine - Valves	8
Engine - Valves Per Cylinder	4
Engine - Valve Configuration	SOHC
Engine - Displacement (cc)	963
Engine - Displacement (ci)	58.7
Engine - Starter	Electric
Engine - Fuel Requirements	Regular
Engine - Fuel Type	Gas
Carburetion	Standard
Carburetion - Carburetion Brand	Bosch
Carburetion - Fuel Injector	Yes
Carburetion - Carburetor	No
Carburetion - Carburetion Type	Fuel Injected

TRANSMISSION

Transmission	Standard
Transmission - Transmission Type	Continuously Variable (CVT)
Transmission - Primary Drive (Rear Wheel)	Shaft
Transmission - Primary Drive (Engine / Transmission)	Chain
Transmission - Reverse	Yes
Transmission - Hi / Low Range	Yes
Transmission - Primary Drive (Front Wheel)	Shaft

TECHNICAL SPECIFICATIONS

Dimensions	Standard
Dimensions - Length (in)	117
Dimensions - Length (mm)	2971.8
Dimensions - Width (in)	63.5
Dimensions - Width (mm)	1612.9
Dimensions - Height (in)	72.8
Dimensions - Height (mm)	1849.1
Dimensions - Wheelbase (in)	80.7
Dimensions - Wheelbase (mm)	2049.8
Dimensions - Turning Radius (ft)	26.9
Dimensions - Ground Clearance (in)	11.4
Dimensions - Ground Clearance (mm)	289.6
Dimensions - Length (ft)	9.75
Dimensions - Length (ft/ft)	9
Dimensions - Length (ft/in)	9
Weight	Standard
Weight - Dry Weight (lbs)	1520
Weight - Dry Weight (kg)	689.5
Weight - Towing Capacity (lbs)	2000
Weight - Towing Capacity (kgs)	907.2
Capacities	Standard
Capacities - Fuel Capacity (gal)	10.5
Capacities - Fuel Capacity (l)	39.7
Performance	Standard
Performance - Engine Displacement to Weight (cc)	0.63

EXTERIOR

Construction	Standard
Construction - Frame	Steel
Construction - Body Material	Plastic
Exterior Guards	Standard
Exterior Guards - Chain Guard	No
Exterior Guards - Engine Case Guard	No
Exterior Guards - Exhaust Guard	Yes
Exterior Guards - Front Mud Guards	No
Exterior Guards - Rear Mud Guards	No
Exterior Covers	Standard
Nerf Bars	Optional
Front Bumper	Optional
Rear Bumper	Optional
Front Fender Flairs	Standard
Rear Fender Flairs	Standard
Skid Plate	Standard
Skid Plate - A-Arm Skid Plate (Front)	Yes
Skid Plate - A-Arm Skid Plate (Rear)	Yes
Skid Plate - Bash Plate (Front)	Yes
Skid Plate - Bash Plate (Rear)	Yes
Skid Plate - Full Length Skid Plate	Yes
Cab Canopy	Standard
Cab Canopy - Cab Canopy Material	Hard
Cab Canopy - Camouflage	No
Cab Cage	Standard
Cab Rollbar	Standard
Cab Doors	Standard
Cab Doors - Cab Door Material	Soft
Cab Doors - Camouflage	No
Cab / Bed Divider	Standard

SUSPENSION

Front Suspension	Standard
Front Suspension - Front Suspension Type	Independent Double A-Arm
Front Suspension - Front Adjustable Fork Pre-Load	Yes
Front Suspension - Front Stabilizer Bar	Yes
Rear Suspension	Standard
Rear Suspension - Rear Suspension Type	Independent Double A-Arm
Rear Suspension - Rear Adjustable Shock / Spring Pre-Load	Yes
Rear Suspension - Number Rear Shock Absorbers	2
Rear Suspension - Rear Suspension Material	Steel
Rear Suspension - Rear Stabilizer Bar	Yes
Rear Suspension - Air Adjustable	No

WHEELS & TIRES

Wheels	Standard
Wheels - Wheels Composition	Aluminum
Wheels - Front Tire Diameter (in)	27
Wheels - Rear Tire Diameter (in)	27
Tires	Standard
Tires - Front Tire Width	9
Tires - Front Wheel Diameter	14
Tires - Rear Tire Width	11
Tires - Rear Wheel Diameter	14
Tires - Front Tire (Full Spec)	27 x 9 - 14
Tires - Rear Tire (Full Spec)	27 x 11 - 14
Tires - Tread Type	All Terrain

BRAKES

Brakes	Standard
Brakes - Front Brake Type	Hydraulic Disc
Brakes - Rear Brake Type	Hydraulic Disc
Engine Braking	Standard

SEATS

Seat	Standard
Seat - Seat Type	Bench
Seat - Seat Material	Vinyl
Seat - Folding	No
Seat - Headrest	Yes
Seat Specifications	Standard
Seat Specifications - Number Of Seats	6
Seat Specifications - Number Of Rows	2
Grab Rail or Strap	Standard

INSTRUMENTATION

Digital Instrumentation	Standard
Clock	Standard
Tachometer	Standard
Trip Odometer	Standard
Speedometer	Standard
Hour Meter	Standard
Temperature Warning	Standard
Temperature Warning - Temperature Warning Type	Gauge
Fuel Level Warning	Standard
Fuel Level Warning - Fuel Level Warning Type	Gauge

STORAGE

Cargo Bed	Standard
Cargo Bed - Bed Capacity (lbs.)	1000
Cargo Bed - Bed Capacity (kgs.)	453.6
Cargo Bed - Cargo Bed Tilt	Yes
Cargo Bed - Integral Tie-Down Hooks	Yes
Front Storage Well	Standard

LIGHTS

Headlight(s)	Standard
Headlight(s) - Type	LED

GLASS

Rearview Mirrors

Standard

CONVENIENCE

Seat Belts

Standard

PAINT & FINISH

Paint	Optional
Paint - Primary Color	Camouflage
Paint - Metallic	No

DRIVE LINE

Driveline	Standard
Driveline - Driveline Type	Selectable 4X2 / 4X4
Driveline - Number Of Driveline Modes	2
Driveline - Rear Unlocking Differential	No
Driveline - Rear Solid Axle	No
Differential Lock	Standard
Differential Lock - Differential Lock Location	Front

STEERING

Steering	Standard
Steering - Steering Type	Power
Steering - Steering Control	Steering Wheel
Tilt Steering	Standard

TOWING & HAULING

Rear Hitch	Optional
Rear Hitch - Size (in)	2
Rear Hitch - Size (cm)	5.1
Rear Hitch - Rear Hitch Type	Receiver
Winch	Standard
Roller Fairlead	Standard

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
