Specifications

Engine

Engine Name	Kawasaki FR691
Horsepower	23 HP
Fuel Capacity	5 Gallons

Drive Line

Hydraulic Drive	Hydro-Gear ZT-2200
Hydraulic Drive Torque	Up to 215 ft-lb
Hydraulic Drive Maintenance	No Maintenance Required
Front Tires	12" Bias Ply
Drive Tires	20x10-10 Carlisle Turf Armor
Wheel Type	Steel

Features

Acreage	Up to 1
Seat	Comfortable, Custom Design
Steering Levers	Soft-Touch Knobs to Adjust Forward and Back. Adjustable Up and Down
Control Panel LCD Display	N/A
Control Panel LED Warning Indicators	N/A
Ignition	Key Switch
Auxiliary Power	N/A
Storage	Cup Holder and Deep Storage Tray
Hitch	N/A
LED Light Bar	N/A

Cutting Deck

Deck Size	54"
Deck Depth	4"
Deck Lift	Foot Operated
Deck Adjustment	Magnetic Pin Height Adjustment
Cut Height	1" to 5" with 15 Cut Heights
Blade Spindles	Cast Aluminum, No Maintenance/Sealed Bearings
Parking Brake	Automatic in Control Arms
Frame	1.5" by 3" Powder Coated Frame

Measurements

Width	54" Deck - 55.5" Wide
Weight	682 - 719 lbs
Length	81"
Height	44"

Warranty

Engine Warranty	3 Year
Hydraulic Drive Warranty	3 Year
Control Panel Warranty	N/A
Product Warranty	3 Year
Battery Warranty	6 Months
Belt Warranty	90 Days

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
