2026 Exmark Radius E-Series RDE691GKA48200

Total Price:    $6,985.98

Highlights

Tishomingo, MS
In Stock
New
2026
Exmark
Radius E-Series RDE691GKA48200
Red
Lawn Mower
Zero-Turn Mower

RECENTLY VIEWED

info specifications
Discover the Exmark Radius E-Series Mower
With the performance you expect from Exmark, new features and a fresh new look, the Radius E-Series is the right choice for home and acreage owners looking for a commercial-grade mower without breaking the bank. Choose from 48-, 54-, or 60-inch Exmark Series 2+ cutting decks and a wide range of available accessories for maximum versatility. And with new Kawasaki V-twin engine options, Radius E-Series models deliver more performance per dollar than ever before.

Adjustable Rollover Protection System (ROPS)
New square tubing rollover protection system (ROPS) is easily foldable for storage.

Height of Cut Made Easy
Exmark’s patented cut height adjustment system is very easy to use, enabling the user to quickly set height of cut with unmatched accuracy, right from the operator seat.

High-Strength Steel Frame
Fabricated and fully welded of high-strength rectangular steel tubing, the Radius frame places the heaviest components –– engine, transmission and fuel tank –– low and centralized in the frame. This lowers the machine’s center of gravity for increased traction and stability. New steel engine guards increase engine protection at the sides and rear of the machine, while also being easily removable for service access.

Series 2+ Cutting Deck
Fabricated and fully welded from high-strength steel, the Exmark Series 2+ cutting decks feature maintenance-free sealed bearing spindle assemblies and durable double-capture anti-scalp rollers to deliver the cut quality and durability you expect from Exmark.

Integrated Hydro Pump and Motor Design
Dual HydroGear ZT-2800 hydro transmissions feature an integrated pump and motor design for maximum efficiency, long-term reliability and ground speeds of up to 8 mph.

Large Drive and Caster Tires
Radius E-Series models are equipped with large, smooth-riding 22-inch drive tires and 13-inch caster tires.

Radius E-Series Model RDE691GKA48200 at a Glance
Fuel Capacity - 7 gallon
Speed - 8 mph
Cutting Height Range - 1.5" - 5.0"
Coverage in Acres - 3-5
Acres Per Hour - 3.10

Features
3.10 Acres/Hour
48" Deck
Kawasaki V-Twin FR691 Engine
Series 2 plus fabricated and welded steel deck

Specifications

Equipment

UPC 193308243740
Width / Cutting Deck 48"
Drive Hydro-Drive
Starter Electric
Steering Control Hydraulically dampened twin levers adjustable both fore and aft. Also has 2-position height adjustment.
Caster Forks .375" thick caster yoke arms.
Front Caster Tires 13 x 6.5-5 smooth-tread, pneumatic.
Drive Tires 22 x 10-10 K3012
Safety Package Operator Presence Controls (OPC) and drive system interlock.
Parking Brake Automatic-actuated pawl brake.
Tractor Frame Unibody, welded, heavy-duty 1.5" x 3" tubular steel.
Blade Spindles No maintenance, sealed and non-greasable spindles; 7.75"-diameter cutter housing with 25mm (.98") diameter spindle shaft.
Cup Holder Yes
Electrical 12 volt battery with 15-amp alternator
Standard Features Hour meter, cup holder, hitch
Seat Deluxe, two-tone, bolstered seat with flip up armrests and integral safety switch
Optional Features Hour meter and seat armrests

Power Components

Engine Brand Kawasaki
Transmission Brand Hydro-Gear
Transmission Speeds Infinitely Variable
Engine Model FR691
Engine Displacement 691
Engine Series V-Twin
Fuel System Carbureted
Speed Infinitely variable speed selection from 0–8.0 mph forward, 0–4.0 mph reverse
Transmission Hydrostatic
Engine Spec AS43-R
Engine Speed 3,600 rpm
Air Filter Standard Engine Manufacturer's air filter
Fuel Capacity 7-gallon single fuel tank with single fill location
Drive Description Two Hydro-Gear ZT-2800 hydro static transmissions with no hoses and integrated cooling fans and integrated reservoir
Fuel Type Gas Carbureted
PTO Engagement Electromagnetic 105-ft-lb clutch
Drive Wheel Release Allows unit movement without engine running.
Fuel Indicator Float gauge
Deck Lift Foot pedal, single point drop pin HOC
Carb Compliant No
ROPS 2-post foldable ROPS standard with seat belt.

Decks

Deck Style Floating Deck
Deck Style Description Series 2 plus fabricated and welded steel deck. Decks have side discharge standard with the option ot bag or mulch.
Deck Construction 7-gauge top that is formed and welded, 12-gauge side skirt and .375" welded bumper. 4 point suspension.
Cutting Heights 1.5" to 5.0" in 0.25 increments
Blade Tip Speed Approximately 18,500 fpm
Blades 3 Blades at 16.50" Length

Dimensions

Width 60.6"
Height 73.7"
Curb Weight 804
Length 83.9"

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
