2026 Exmark Vertex S-Series VXS740EKC60400

Highlights

Tishomingo, MS
In Stock
New
2026
Exmark
Vertex S-Series VXS740EKC60400
Red
Lawn Mower
Stand-On Mower

RECENTLY VIEWED

info specifications
Discover the Exmark Vertex S-Series Mower
The Vertex S-Series stand-on zero-turn mowers are ready to take your productivity and profitability to the next level. With a design that centralizes mass low in the mower chassis, Vertex is ultra-maneuverable, yet stable and easy to control. The control panel is ergonomically designed and centrally located to improve operator comfort. Exmark's proven hydro drive system delivers ground speeds of up to 8.5mph, enabling Vertex to quickly finish large jobs. Built with a Kawasaki V-Twin or Kohler EFI engine to increase fuel efficiency so you can stay out in the field longer. Choose from 48-, 52-, or 60-inch UltraCut Series 4 side-discharge cutting decks, featuring easy rake adjustment and anti-scalp rollers, for an Exmark signature finish cut quality every time.

Design Simplicity
Operating a Vertex mower is easy, thanks to the simple, ergonomic design. Key, choke, throttle, height of cut adjustment...they're all right there. Hop on, and you're ready to go.

Operator Comfort
Designed to place the operator in a position of comfortable control. The wide, open platform offers more room for the operator to adjust their stance, while the ergonomic control panel places all vital controls close for easy reach and operation.

Cut Quality
All models are equipped with Exmark UltraCut Series 4 side-discharge cutting decks. The decks feature flow-control baffles, anti-scalp rollers, and a rod-style floating deck design for easy deck rake adjustments. The result is a signature cut quality on any turf type.

Reduced Maintenance
With no in-season grease points, flat-free semi-pneumatic front caster tires, and maintenance-free sealed bearing cutter housings, Vertex S-Series is designed to minimize in-season maintenance and the downtime that goes with it.

Ease Of Service
These units are easy to service thanks to the tools-free access to the engine and hydro drive components. The reliable single-belt drive system is simple and easy to maintain, and Exmark’s patented spherical idler bearings require only annual lubrication.

Commercial Engine
Choose from a fuel-saving EFI Kohler or carbureted Kawasaki commercial engine. Both engines feature heavy-duty canister-style air filtration systems and pressurized lubrication for maximum durability in daily commercial use.

Single-Point Height of Cut
The single-point height of cut makes it easy to accurately set deck height without tools. This enables the operator to quickly change cut height by simply raising and lowering the deck.

Ultracut Series 4 Deck
Built from formed and welded high-strength steel, UltraCut Series 4 full-floating decks feature maintenance free spindles with splined blade drivers to stop bolt tightening on impacts. The idler arm pivot bearings are also maintenance free.

Vertex S-Series Model VXS740EKC60400 at a Glance
Fuel Capacity - 8 gallon
Speed - 8.5 mph
Cutting Height Range - 1.5" - 5.0"
Coverage In Acres - 3-5
Acres Per Hour - 4.11

Features
4.11 Acres/Hour
60" Deck
Command™ EFI ECV740 Engine
Rehlko Engine
Full-floating UltraCut Series 4

Specifications

Equipment

UPC 193308221847
Starter Electric
Steering Control Twin levers with center fixed reference bar for ease of control forward and reverse
Front Caster Tires 13 x 5.0-6, smooth-tread, semipneumatic tires with tapered roller bearings.
Drive Tires 25 x 10.0-8 Carlisle Turf Master
Parking Brake Lever-actuated bar brake.
Tractor Frame Welded, heavy-duty 1.5" x 2.5" tubular steel.
Blade Spindles No maintenance, sealed and nongreasable spindles; 7.75" diameter cutter housing with 1.75" diameter splined blade driver 1.0"-diameter spindle shaft.
Cup Holder Yes
Electrical 12-volt battery with 15-amp alternator.
Standard Features Enhanced Engine Hour Meter

Decks

Deck Style Floating Deck
Deck Style Description Full-floating UltraCut Series 4. Side discharge standard, with molded discharge chute and option to bag or mulch.
Width / Cutting Deck 60"
Deck Construction 10-gauge top that is formed and continuously seam welded, 7-gauge side skirt
Cutting Heights 1.5" to 5.0" in 0.25" increments
Blade Tip Speed Approximately 18,500 fpm
Blades 3 Blades at 20.50" Length

Dimensions

Width 72.87"
Height 49.2"
Curb Weight 1026
Length 68.24"

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
