Equipment
| UPC | 193308241005 |
| Starter | Electric |
| Steering Control | Hydro drive with Enhanced Control System (ECS), forward/reverse, left/right or zero-turn. |
| Front Caster Tires | 11 x 4.0-5, smooth tread, semi-pneumatic. |
| Drive Tires | 18 x 8.5-8, 4-ply Turf Master® |
| Safety Package | Operator Presence Controls (OPC). Operator must have speed control lever in neutral and blades disengaged to leave operator’s position without stopping engine |
| Parking Brake | Lever-actuated mechanical compression. |
| Electrical | 12-volt battery with 20-amp alternator. |
| Standard Features | Enhanced engine hour meter |
Power Components
| Transmission Brand | Hydro-Gear |
| Transmission Speeds | Infinitely Variable |
| Engine Brand | Rehlko |
| Engine Model | ECV732 |
| Engine Displacement | 747 |
| Transmission | Hydrostatic |
| Speed | Infinitely variable speed selection from 0– 6.75 mph forward, 0–2.25 mph reverse |
| Engine Series | Command™ EFI |
| Fuel System | Electronic Fuel Injected |
| Drive | Hydro-Drive |
| Engine Spec | 3051 |
| Engine Speed | 3,600 rpm |
| Fuel Capacity | 5-gallon single fuel tank with single fill location |
| Air Filter | Heavy-duty canister air filtration system |
| Drive Description | Twin Hydro-Gear variable-displacement pumps and twin high-efficiency Parker/Ross wheel-drive motors with 1" tapered shafts. |
| PTO | Engagement Electromagnetic 200 ft-lbs clutch |
| Fuel Type | Gas EFI |
| Drive Wheel Release | Allows unit movement without engine running. |
| Fuel Indicator | None |
| Deck Lift | Manual lift with hairpin from hole to hole for position adjustment. |
| Carb Compliant | No |
Decks
| Deck Style | Floating Deck |
| Deck Style Description | Full-floating UltraCut Series 3, side discharge standard, with molded discharge chute and option to bag or mulch. |
| Width / Cutting Deck | 60" |
| Deck Construction | 10-gauge top that is formed and continuously seam welded, 7-gauge side skirt and 7-gauge welded spindle mounting locations for improved strength. |
| Cutting Heights | 1.5" to 4.5" in 0.5" increments |
| Blade Spindles | No maintenance, sealed and non-greasable spindles; 7.75"-diameter cutter housing with 25mm (.98") diameter spindle shaft and splined blade driver. |
| Blade Tip Speed | Approximately 18,500 fpm |
| Blades | 3 Blades at 20.5" Length |
Dimensions
| Width 73" | Width 73" |
| Height 45" | Height 45" |
| Curb Weight | 840 |
| Length | 104.8" |
Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
