Total Price: $6,999.00
Engine
Engine Type | Prostar 4-Stroke DOHC Single Cylinder |
Cylinders-Displacement (cc) | 567cc |
Cooling | Liquid |
Engine Power | 44 HP |
Electronic Power Steering | Standard |
Fuel System | Electronic Fuel Injection / 340 CCA |
Drivetrain
Drive System | One Touch On-Demand AWD/2WD |
Transmission | Automatic PVT P/R/N/L/H In-line Shifting |
Suspension
Front Suspension | Sealed MacPherson Strut |
Rear Suspension | Sealed Dual A-Arm, IRS |
Front Travel (in./cm.) | 8.2 in (20.8 cm) |
Rear Travel (in./cm.) | 9.5 in (24.1 cm) |
Brakes
Front braking system | Single Lever 3-Wheel Hydraulic Disc with Hydraulic Rear Foot Brake |
Rear braking system | Single Lever 3-Wheel Hydraulic Disc with Hydraulic Rear Foot Brake |
Parking Brake | Park In-Transmission / Lockable Hand Lever |
Wheels & Tires
Wheels | Steel |
Front Tire | 25x8-12 P373; 6 PLY |
Rear Tire | 25x10-12 P373; 6 PLY |
Dimensions
Ground Clearance | 11.5 in (29 cm) |
Overall Vehicle Size (LxWxH) | 83 x 48 x 47 in (210.8 x 121.9 x 119.4 cm) |
Wheelbase | 50.5 in (128.3 cm) |
Hitch/Type | Standard 1.25 in (3.2 cm) Receiver |
Seat Height | 33.25 in (84.5 cm) |
Capacities
Fuel Capacity | 4.5 gal (17.0 L) |
Payload Capacity | 485 lb (220 kg) |
Front/Rear Rack Capacity | 90 lb /180 lb (40.8 kg /81.6 kg) |
Weights
Estimated Dry Weight (lbs./kgs.) | 753 lb (342 kg) |
Hitch Towing Rating | 1,350 lb (612 kg) |
Lights and Safety
Lighting | Halogen Pod & Bumper Lights, Triple 50w High Beams, Dual 50w Low Beams, Twin LED Brake Lights/Taillights |
Features
Cargo System | Lock & Ride Compatible 5 Gal (18.9L) Front Dry Storage |
Features | Other Standard: Front Trail Bumper, Front & Rear Rack Extenders, In Pod Battery Charger, 12 Volt Power Plug, Pre-Wired for Hand & Thumb Warmers, Winch & Plow Mounts Included |
Instrumentation | All Digital Gauge, Speedometer, Odometer, Tachometer, Two Tripmeters, Hour Meter, Gear Indicator, Fuel Gauge, AWD Indicator, Volt Meter, Coolant Temperature, Hi-Temp Light, Clock |
Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
