Total Price: $7,399.00
Engine
Engine Type | Single cylinder, 4-stroke, SOHC, 4-valve |
Displacement | 580cc |
Cooling System | Liquid cooled |
Engine Power | 45 HP @ 6500 RPM |
Engine Torque | 38 LB-FT @ 6000 RPM |
Starter | Electric |
Fuel System | Bosch® EFI |
Drivetrain
Transmission | CVTech® Automatic L/H/N/R/P |
Suspension
Front Suspension | Double A-arm independent |
Rear Suspension | Double A-arm independent |
Front Shocks | Spring pre-load adustable, oil damped |
Rear Shocks | Spring pre-load adustable, oil damped |
Brakes
Brake System Type | Hydraulic disc with parking brake |
Wheels & Tires
Front Wheel | 12” Cast aluminum alloy |
Rear Wheel | 12” Cast aluminum alloy |
Front Tire | 25” x 8” x R12 |
Rear Tire | 25” x 10” x R12 |
Dimensions
Hitch/Type | Receiver: 2” |
Seat Height | 21” |
Ground Clearance | 10.6” |
Overall Vehicle Size (LxWxH) | 80.1” x 46.5” x 48” |
Capacities
Fuel Capacity | Tank: 4.75 gal |
Towing Capacity | 1500 lbs. |
Rack capacity, front | 75 lbs |
Rack capacity, rear | 100 lbs |
Weights
Weight | Winch: 3500 lbs. |
Curb Weight | 871 lbs |
Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
